Kettle Sets

Check out our design guides and tips! Want a simple non-recirulating BIAB system? More information can be found on the product information page.

Our new bottom drain kettles open up a range of options to build your ideal brewery. Your system design will depend significantly on how you want to install your kettles. Once you have decided on a brew stand, you can build your own 1, 2, or 3 kettle recirculating brew system using one or more of our "building block" sets. To build a complete system, choose your kettle set(s) and add your choice of pump, connections, and controller:

The kettle sets include the clamps and gaskets you need to make the connections directly to the kettle. External hoses and additional fittings will require the purchase of additional clamps and gaskets. As a rule of thumb, add one clamp and gasket for every hose barb, valve, and Tri-Clamp fitting that you add to your order to complete the set.

Using an open brew stand makes for easy access under the kettle, but you can also work with a normal table and short leg extensions. Just make sure the system is not too tall to easily reach inside - this becomes more of an issue with 60L and larger systems. Another easy and cost effective option is to bolt the kettles directly to the floor using our extension legs and foot mounting plates. Always make sure your table or stand can support the weight of the system and is secured against tipping!
